Stäubli MC4 and MC4-Evo2 Crimping Pliers PV-CZM-60100 for cross section 4/6/10mm².

The Stäubli PV-CZM-60100 is an original professional crimping tool designed for open B-crimp contacts used with Stäubli MC4 and MC4-Evo2 connectors. Supplied with the appropriate crimping die and locators, it enables precise, repeatable crimps for 4 mm², 6 mm², and 10 mm² conductors (12–8 AWG), ensuring reliable electrical connections that meet Stäubli's assembly requirements.

The PV-CZM-60100 includes MC4 and MC4-Evo2 locators together with the corresponding crimping die, allowing one tool to service both connector systems. TÜV and UL certified, it features Stäubli's registered crimp die identification system, providing traceability by marking each crimp with information about conductor size, crimp height, and crimp width.

Key Features

• Original Stäubli crimping pliers
• Official product designation PV-CZM-60100
• Designed for open B-crimp contacts
• Compatible with original MC4 and MC4-Evo2 connectors
• Crimping range: 4 mm², 6 mm², and 10 mm² (12–8 AWG)
• Includes MC4 locator, MC4-Evo2 locator, and crimping die
• Interchangeable crimping die and locators
• TÜV and UL certified
• Registered crimp die identification for traceable crimps
• Professional tool for photovoltaic connector assembly

The Stäubli PV-CZM-60100 Crimping Pliers provide precise, repeatable crimping for the professional assembly of original MC4 and MC4-Evo2 photovoltaic connectors.

More information about Crimping Pliers PV-CZM-60100:

• Datasheet
