Stäubli MC4 & MC4-Evo2 PV Installer Tool Case SET.

The Stäubli PV-Installer Tool Case SET is a comprehensive professional tool kit containing all the original tools required for the installation and maintenance of Stäubli MC4 and MC4-Evo2 photovoltaic connectors. Supplied in a robust plastic case with a custom foam insert, it is configured for 4 mm², 6 mm², and 10 mm² open B-crimp contacts, making it an ideal solution for professional PV installers and service technicians.

The case includes original Stäubli crimping pliers, torque tool set, stripping pliers, cable cutter, assembly and unlocking tools, MC4 and MC4-Evo2 test plugs, locators, and sealing caps. Every tool is designed, tested, and approved by Stäubli to ensure safe, efficient, and reliable assembly of original MC4 connector systems in the field.

Tool Case SET includes:

• PV-CZM-60100 crimping pliers
• PV-WZ-TORQUE-SET torque tool set
• PV-AZM-410 stripping pliers
• PV-WZ-KS cable cutter
• PV-MS-PLS assembly and unlocking tool set
• PV-PST MC4 test plug
• PV-EVO-PST MC4-Evo2 test plug
• PV-LOC-MC4 and PV-LOC-MC4-Evo2 locators
• PV-SVK4 and PV-BVK4 sealing caps (10 pcs. each)

Key Features

• Original Stäubli PV Installer Tool Case
• Official product designation PV-Installer Tool Case SET
• Complete installation kit for original MC4 and MC4-Evo2 connectors
• Configured for 4 mm², 6 mm², and 10 mm² open B-crimp contacts
• Robust plastic case with custom foam insert
• Designed, tested, and approved by Stäubli for professional photovoltaic installations
• Case dimensions: 444 × 350 × 118 mm


The Stäubli PV-Installer Tool Case SET provides everything needed for the professional installation and servicing of original MC4 and MC4-Evo2 photovoltaic connectors in one convenient case.

More information about PV-Installer Tool Case SET:

• Datasheet
